Phone Features Codecs and Voice Features Physical Features 3 VoIP accounts, Hotline, Emergency call Call hold, Call waiting, Call forward, Call return Call transfer (Blind/Semi-attended/Attended) Caller ID display, Redial, Mute, DND Auto-answer, 3-way conferencing Speed dial, SMS, Voicemail Message Waiting Indication (MWI) LED Tone scheme, Volume control Direct IP call without SIP proxy Ring tone selection/Import/Delete Phonebook (1000 entries), Black list Call history: Dialed/Received/Missed/Forwarded Menu-driven user interface Localized language and input method Soft keys programmable
Advanced Features XML phonebook search/import LDAP phonebook XML Idle Screen Action URL & Active URI Wallpaper, Screensaver Color Picture Caller-ID Theme, Screen Sleep
IP PBX System Integration Busy lamp field (BLF), BLF list, (BLA) DND & Forward synchronization Intercom, Paging, Music on hold Call park, Call pickup Call recording, Call completion Group listening, Group pickup Anonymous call, Anonymous call rejection Network conference Distinctive ringtone Dial Plan, Dial-now Wideband codec: G.722 Narrowband codec: G.711μ/A, G.723.1,G.726, G.729AB VAD, CNG, AEC, PLC, AJB, AGC Full-duplex speakerphone with AEC Network Features SIP v1 (RFC2543), v2 (RFC3261) DNS SRV (RFC3263) Redundant server support NAT Traversal: STUN mode DTMF: In-Band, RFC2833, SIP Info Proxy mode and peer-to-peer SIP link mode IP Assignment: Static/DHCP/PPPoE Bridge/router mode for PC port TFTP/DHCP/PPPoE client HTTP/HTTPS server DNS client, NAT/DHCP server Logout
Management Auto-provision via FTP/TFTP/HTTP/HTTPS Auto-provision with PnP SNMP V1/2 optional, TR069 optional Configuration: browser/phone/auto-provision Factory configuration customized Trace package and system log export Security Open VPN, 802.1x, VLAN QoS (802.1pq), LLDP Transport Layer Security (TLS) HTTPS (server/client), SRTP (RFC3711) Digest authentication using MD5/MD5-sess Secure configuration file via AES encryption Phone lock for personal privacy protection Admin/VAR/User 3-level configuration mode 2xRJ45 10/100/1000Mbps Ethernet ports TI Aries chipset 3” TFT-LCD, 400 x 240 pixel, 262K colors 32 keys including 3 programmable keys 5 LEDs: 1 x power, 3 x line, 1 x message Wall-mountable 1xRJ9 (4P4C) handset port 1xRJ9 (4P4C) headset port Power adapter (optional):
AC 100~240V input and DC 5V/2A output Power over Ethernet (IEEE 802.3af) Power consumption: 4.0W Net weight: 0.77kg Dimension: 185 x 200 x 90mm Operating humidity: 10~95% Storage temperature: up to 60°C
Package Features Qty/CTN: 10 PCS N.W/CTN: 12.020KG G.W/CTN: 14.100KG Measurement: 0.083CMB Carton Meas: 560*460*250MM
|
