Audio Features
> HD voice: HD handset, HD speaker
> Wideband codec: G.722
> Narrowband codec: G.711(A/μ), G.723.1,G.729AB, G.726
> DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO
> Full-duplex hands-free speakerphone with AEC
> VAD, CNG, AEC, PLC, AJB, AGC
Phone Features
> 6 VoIP accounts
> One-touch speed dial, redial
> Call forward, call waiting
> Call transfer, call hold
> Call return, group listening
> Mute, auto answer, DND
> 3-way conference call
> Direct IP call without SIP proxy
> Ring tone selection/import/delete
> Hotline, emergency call
> Set date time manually or automatically
> Dial Plan
>XML Browser
> Action URL/URI
> RTCP-XR （RFC3611）,VQ-RTCPXR（RFC6035）
Directory
> Local phonebook up to 1000 entries
> Black list
> XML/LDAP remote phonebook
> Intelligent search method
> Phonebook search/import/export
> Call history: dialed/received/missed/forwarded
IP-PBX Features
> Busy Lamp Field (BLF)
> Bridged Line Apperance(BLA)
> Anonymous call, anonymous call rejection
> Hot-desking
> Message Waiting Indicator (MWI)
> Voice mail
>Call park, call pickup
> Intercom, paging
> Music on hold
> Call recording
Display and Indicator
> 2.7" 192x64-pixel graphical LCD with backlight
> LED for call and message waiting indication
> Dual-color (red or green) illuminated LEDs for line status information
> Intuitive user interface with icons and soft keys
> National language selection
> Caller ID with name, number
Feature keys
> 6 line keys with LED
> 6 line keys can be programmed up to 15 various features (3-page view)
> 5 features keys: message, headset, mute, redial, hands-free speakerphone
> 4 context-sensitive “soft” keys
> 6 navigation keys
> 2 volume control keys
> Illuminated mute key
> Illuminated headset key
> Illuminated hands-free speakerphone key
Interface
> 2xRJ45 10/100M Ethernet ports
> 1xRJ9 (4P4C) handset port
> 1xRJ9 (4P4C) headset port
> 1XRJ12 (6P6C) EHS port
> Power over Ethernet (IEEE 802.3af), Class 2
Other Physical Features
> Stand with 2 adjustable angles
> Wall mountable
> External universal AC adapter (optional)：AC 100~240V input and DC 5V/1.2A output
> Power consumption (PSU): 1.1-2.3W
> Power consumption (PoE): 1.7-3.2W
> Dimension(W*D*H*T): 212mm*189mm*175mm*54mm
> Operating humidity: 10~95%
> Operating temperature: -10~50°C
Package Features
> Qty/CTN: 5 PCS
> N.W/CTN: 6.3kg
> G.W/CTN: 7.0kg
> Giftbox size: 246mm*223mm*120mm
> Carton Meas: 627mm*256mm*235mm
Management
> Configuration: browser/phone/auto-provision
> Auto provision via FTP/TFTP/HTTP/HTTPS for mass deploy
> Auto-provision with PnP
> BroadSoft device management
> Zero-sp-touch TR-069
> Phone lock for personal privacy protection
> Reset to factory, reboot
> Package tracing export, system log
Network and Security
> SIP v1 (RFC2543), v2 (RFC3261)
> Call server redundancy supported
> NAT transverse: STUN mode
> Proxy mode and peer-to-peer SIP link mode
> IP assignment: static/DHCP
> HTTP/HTTPS web server
> Time and date synchronization using SNTP
> UDP/TCP/DNS-SRV(RFC 3263)
> QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS DSCP
> SRTP for voice
> Transport Layer Security (TLS)
> HTTPS certificate manager
> AES encryption for configuration file
> Digest authentication using MD5/MD5-sess
> OpenVPN, IEEE802.1X
> IPv6
|
